Electromagnetic immunity
Emission measurements IEC-60601 test level Compliance level
Discharge of static electricity in accordance
with IEC 61000-4-2
± 8 kV contact discharge
± 15 kV air discharge
± 8 kV contact discharge
± 15 kV air discharge
Floors should be made of wood or concrete
or covered with ceramic tiles.
Electrical fast transient/burst immunity
in accordance with IEC 61000-4-4
± 2 kV for power cables
± 1 kV for input/output cables
± 2 kV for power cables
± 1 kV for input/output cables
The quality of the supply voltage should
correspond to that of a typical store or
clinic environment.
Impulse voltage/surges in accordance
with IEC 61000-4-5
± 1 kV voltage phase conductor –
phase conductor
± 2 kV voltage phase conductor – ground
± 1 kV voltage phase conductor –
phase conductor
± 2 kV voltage phase conductor – ground
Magnetic field at supply frequency (50/60 Hz)
in accordance with IEC 61000-4-8 3 A/m 3 A/m
Voltage dips, short-term interruptions
and fluctuations in the supply voltage
in accordance with IEC 61000-4-11
< 5 % U
T
for 1/2 period (> 95 % dip)
< 40 % U
T
for 10 periods (60 % dip)
< 70 % U
T
for 25 periods (30 % dip)
< 5 % U
T
5 s (> 95 % dip)
< 5 % U
T
for 1/2 period (> 95 % dip)
< 40 % U
T
for 10 periods (60 % dip)
< 70 % U
T
for 25 periods (30 % dip)
< 5 % U
T
5 s (> 95 % dip)
The quality of the supply voltage should
correspond to that of a typical store or clinic
environment. If the users of the device require
continuous operation, even in case of power
outages, it is recommended to feed power to
the device via an uninterruptible power
supply or a battery.
Radiated fields in close proximity in
accordance with IEC 61000-4-39
8 A/m at 30kHz
65 A/m at 134.2kHz 7.5 A/m at 13.56kHz
8 A/m at 30kHz
65 A/m at 134.2kHz 7.5 A/m at 13.56kHz
Avoid exposure to known sources of EMI
(electromagnetic interference) such as
diathermy, lithotripsy, electrocautery, RFID
(Radio Frequency Identification), and electro-
magnetic security systems such as anti-theft/
electronic article surveillance systems, metal
detectors. Note that the presence of RFID
devices may not be obvious. If such interfe-
rence is suspected, reposition the equipment
if possible, to maximize distances
Remark: U
T
is the AC mains voltage prior to applying the test level
