4. Installation and connection
Dimension diagram, drawing for screw fixing, push-wire terminal
connection
Ensure that there is no voltage in the installation area and
follow the rules for working on electrical equipment!
DANGER
90 mm
45
67,5
36 mm
31,1
47,5
70,5
2
2
1
2
3
107 mm
