Bender RCMA423-DM User Manual

Installation and connection
21
RCMA423-DM_D00064_03_M_XXEN/06.2017
Legend for wiring diagram RCMA423-DM
Term inal Connections
A1, A2 Connection to supply voltage U
s
k, l Connection for measuring current transformer
T/R Connection to combined test and reset button
M+ (Common) positive pole of the analogue interface
μA Current output 0…400 µA
mA Current output 0…20 mA/4…20 mA
V Voltage output 0…10 V
