10
SMARTIRE SYSTEMS INC.
Alerts and Warnings
PRESSURE DEVIATION ALERT
The Pressure Deviation Alert is initiated
when the measured tire pressure deviates
from the required pressure by more than the pre-
set level.
The alarm light turns on and alert indicator flashes
on and off. The audible alarm sounds once and
the digital readout displays the amount of
deviation e.g. -6 PSI from required pressure.
Press any button to acknowledge the alert and
stop the flashing; the alarm light remains on and
the system returns to normal mode.
Example:
Pressure Deviation Alert Level = +- 6 PSI (0.41 Bar)
Required Pressure = 35 PSI (2.40 Bar)
Actual Pressure in a wheel drops to 29 PSI (2 Bar)
Pressure Deviation reading (as shown) will be
-6 PSI (0.41 Bar)
When the alert occurs, reduce speed and proceed
to a safe location to check tires.
The Pressure Deviation Alert is cancelled when
the tires are properly re-inflated to correct levels.
-6 PSI = -.41 Bar
