BENDIX SmarTire User Manual

Installation and Service
INSTALLATION
The Full Function Display is installed by removing the front bezel of the Basic
Receiver, and install as below.
The Full Function Remote Display is connected to the Receiver via a cable as shown
below.
REMOVE BEZEL FROM R ECEIVER
F ULL F UNCTION D ISPLAY
ONTO FRONT OF
R ECEIVER
F ULL F UNCTION R EMOTE D ISPLAY
R ECEIVER CABLE END PLUG
F ULL F UNCTION R EMOTE D ISPLAY
CABLE END CONNECTION
26
SMARTIRE SYSTEMS INC.
