22
Mounting Requirements
Mounting Requirements - Driver Interface Unit (DIU)
The Driver Interface Unit (DIU) serves as the Bendix
™
VORAD
®
Collision Warning System's central information center. The DIU provides
the driver with visual and audible alerts, as well as system confi guration, status, and diagnostic information. The DIU uses the vehicle's
SAE J1939 data link to communicate with the FLR, and other vehicle system devices.
Mounting Orientation
Torque Specifi cation
Recommended mounting screws #6x19 Plastite thread forming screw, 3/8" (9.52mm) long. Torque mounting screw to 7 lbs. in. ±0.7
(0.79N•m ±0.08) maximum.
1.97"
(50mm)
3.67"
(93.18mm)
3.67"
(93.18mm)
0.38"
(9.76mm)
(73.7mm)
0.38"
(9.76mm)
1.65"
0.91"
