GrandPrix (GP-7 Series) Two-Post Lifts 44 P/N 5900209 — August 2018 — Rev. C2
Tip If you have not yet torqued the Anchor Bolts in order to make it easier to install the Top
Trough and to perform final leveling, you can torque them once you have confirmed that
the lift is level.
Connecting the Power Unit
This section describes how to connect your lift’s Power Unit to the Hydraulic System and to the
220 VAC power source.
⚠ DANGER Installing a Thermal Disconnect Switch
must
be performed by a licensed, certified
electrician.
To connect the Power Unit:
1. Connect the Power Unit to the Hydraulic System.
2. Double check to make sure that there is Hydraulic Fluid in the reservoir.
3. Have a certified, licensed electrician run the power supply to the motor.
Refer to Wiring Diagram for proper wiring information.
⚠ DANGER Risk of explosion: This equipment has internal arcing or parts that may spark and
should not be exposed to flammable vapors. The Power Unit’s motor should not be
located in a recessed area or below floor level. Never expose the motor to rain or
other damp environments; damage to the motor caused by water is not covered by
the warranty.
