HD-973P Series Multi-Level Parking Lift 61 P/N 5900076 — Rev. B3 — January 2024
• Use a separate circuit breaker for each Power Unit.
• Protect each circuit with a time-delay fuse or circuit breaker.
• Use wire of an appropriate gauge for the electrical current and length of run.
To connect the Lift to a power source:
Have a certified, licensed Electrician remove the pigtail and connect an appropriate plug to the
wiring, coming out of the Power Unit (called the “Pigtail” in the drawings above).
The plug is not supplied with the Lift.
Connect the power source cable to the plug you just connected.
Refer to Wiring Diagrams for proper wiring information.
The power source cable is not supplied with the Lift.
Wire the Microswitch(es) to the incoming power source.
Refer to Wiring Diagrams for proper wiring information.
Double check to verify the Hydraulic Fluid Reservoir has an adequate supply of fluid.
⚠ WARNING Do not run the Lift without an adequate supply of Hydraulic Fluid; you will damage
the Power Unit.
