MD-6XP Mid-Rise Scissor Lift 9 P/N 5900108 — Rev. F — March 2020
Model MD-6XP
Lifting capacity 6,000 lbs. / 2,722 kg
a Lifting Height (no Pads)*
47" (3.9 feet) / 1,190 mm
b Overall Width
41.5" (3.6 feet) / 1,054 mm
c Overall Length
76" (6.4 feet) / 1,930 mm
d Frame Length
60" (5 feet) / 1,524 mm
Lowered Height 4.75" / 121 mm
Top Locking Position (no Pads)** 42" (3.5 feet) / 1,067 mm
Middle Locking Position (no Pads)** 33.25" (2.8 feet) / 844 mm
Bottom Locking Position (no Pads)** 22" (1.8 feet) / 562 mm
Raising/Lowering Time*** 45 seconds
Motor**** 115/220 VAC, 50/60 Hz, 1 Ph
* Distance is from ground to top of Platform; does
not
include height of Arms or Pads.
**
For height comparison only;
do not raise a Vehicle without Lift Pads
.
*** Lowering is much slower with no Vehicle on the Lift.
**** Must specify at time of ordering.
Specifications subject to change without notice.
