BendPak XPR-12CL Service Manual

BendPak XPR-12CL
46 pages
To Next Page IconTo Next Page
To Next Page IconTo Next Page
To Previous Page IconTo Previous Page
To Previous Page IconTo Previous Page
Page #3 background imageLoading...
Page #3 background image
168.701in
4285.0mm
119.409in
3033.0mm
[5.618-74.618"]
142.7-1895.1mm
[13.016-82.016"]
330.6-2083.2mm
WITH 63mm [2.5"] &
125mm [5"] ADAPTERR
142.402in
3617.0mm
104.843in
2663.0mm
DRIVE THRU
155.157in
3941.0mm
[29.724-57.992in]
755-1473mm
SHEET 2 OF 3
REV
DWG. NO.
A
SIZE
TITLE:
V
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
5260567
XPR-12CL PRODUCTION
LIFT VER E
1:50
SCALE:
