NOTE:
REFER TO THE DOCUMENTATION THAT CAME
WITH THE POWER UNIT FOR THE LOCATION OF
POWER PORT.
8. Remove plug from Power Unit and install the 90*
Fitting w/ O-ring into the Power Port on the Power Unit.
Use Teflon Tape on the Pipe Fitting side ONLY.
9. Run the Power Unit Hose up the outside of the
Powerside Column and connect to the Power Unit
Fitting. (See Fig. 10.5)
STEP 11
(Routing the Equalizer Cables)
WARNING!
WHEN THE CABLE ADJUSTING NUTS BOTTOM OUT
ON THE THREADED END OF THE CABLE
CONNECTOR AND THERE IS STILL SLACK IN THE
CABLES, THE CABLES HAVE STRETCHED BEYOND
THE SAFE USEFUL LENGTH AND NEED TO BE
REPLACED WITH FACTORY APPROVED CABLE
ASSEMBLIES. DO NOT PLACE WASHERS, SPACERS
OR OTHER DEVICES TO “SHORTEN” THE
EFFECTIVE CABLE LENGTH AS DAMAGE TO THE
LIFT OR INJURY TO PERSONS MAY OCCUR.
Fig. 10.5
