43
DIMENSIONS ARE IN MM
☺
REVISION
REV
DESCRIPTION
DATE
EDITED BY
ECO#
F
REPLACED PARTS:CABLE NUTS WITH 5535025,
WASHER Ø50x20x3mmW WITH
5545342,POWER UNIT MOUNTING BOLTS WITH
5530010,SAFETY COVER BOLTS WITH 5530114,
CHANGED TEE FITTING DESCRIPTION
06/05/2008
TM
00180
G
UPDATED REV ON ITEM IN BOM (XPR-9F,
XP/XPR-9FD
2.4mm x 6858LG.SAFETY CABLE)
07/23/2008
GJ
00226
J
UPDATED DRAWING, UPDATED BOM REVISION,
REPLACED 800335 WITH 5570103, REPLACED
OVAL SLEEVE WITH 5580210, REPLACED 90-
.25Long ElbowORing WITH 5550103,
REPLACED 801105 WITH 5715003, ADDED
FOOT GUARDS FG-800420, FG-801014, FG-
801017, 5730014, 5730015, ADDED HHB M10 x
1.5 x 10
09/25/2008
TM
00220
ITEM
NO
PART NUMBER
DESCRIPTION
QTY
REV
1 800295
XP/XPR-9F/FX OFF SIDE POST ASSEMBLY
1
C
2 801073
XPR-9F/FX POWER SIDE POST ASSEMBLY
1
F
3 800100
XP/XPR POWER SIDE SAFETY WELDMENT
1
B
4 800104
XP/XPR OFF SIDE SAFETY WELDMENT
1
B
5 800106
SLIP ON LIFT PAD ASSEMBLY
4
PRE-005
6 800112
OFF SIDE COVER
2
A
7 800124
XP/XPR-9/10 SHEAVE ASSEMBLY
6
B
8 800191
SAFETY CLEVIS PIN
2
C
9 800207
MX/XP/XPR/RJ SHORT LIFT PAD EXTENSION (113mm LG.)
4
D
10 800208
MX/XP/XPR LONG LIFT PAD EXTENSION (182mm LG.)
4
D
11 800299
XP/XPR-9-F GROUND PLATE
1
B
12 800300
XP/XPR-9-F/FX TOP EQUALIZER PULLEY PLATE WELDMENT
2
B
13 800309
XP/XPR-9-F/FX CHAIN ROLLER ASSEMBLY
2
C
14 800316
XP/XPR-9F/FX, XP-12F CYLINDER LEVELING PLUG
2
C
15 800325
Ø6.35 x 2985LG. POWER UNIT HYDRAULIC HOSE ASSEMBLY
1
B
16 800330
XP/XPR-9F/FX 3/8" NPT TUBE FITTING
2
C
17 5570103
XP/XPR-9-F HYDRAULIC HOSE ASSY Ø6.35 x 1359mm
2
A
18 800693
XPR-9F, XP/XPR-9FD Ø2.4mm x 7214 SAFETY CABLE
1
C
19 800750
XPR-9/10 LIFT HEAD PIN WELDMENT
4
C
20 800868
XPR-9F/FX LIFT HEAD ASSEMBLY
2
D-003
21 801074
EQUALIZER CABLE ASSY Ø10mm x 9646LG
2
C
22 5715003
POWER UNIT VIBRATION DAMPENER
1
A
23 800332
XP/XPR-9F/FX CYLINDER CHAIN
2
B
24
LP-800979
ALL XPR-9, XPR-10C/CX LOW PROFILE MEDIUM ARM ASSEMBLY
2
G
25
LP-800987
XPR-9F/FD/10C/AC LOW PROFILE TRIPLE TELESCOPING ARM
2
F
26 700583
CYLINDER ASSEMBLY Ø 2.5 x 37
2
A
27
AB-1551 POWER UNIT
POWER UNIT
1
--
28 5580210
Ø2.4mm OVAL CABLE CRIMP
1
--
29 5545347
WASHER, M12 FLAT WASHER
2
--
30
16 DIA. HAIRPIN COTTER
Ø3.75 x 68mm
2
--
31 800200
2.5 WIRE DIA., Ø25.5x150 LG.
2
B
32
HN M12 X 1.75
HEX NUT
2
--
33 5535025
NUT M18 x 2.5 NL
2
--
34 5545342
WASHER M18 FLAT
2
--
35 5530010
HHB M8 x 1.25 x 25
4
--
36
8 x 15 x 2 LW
SPRING LOCK WASHER
4
--
37
HN M8 x 1.25
HEX NUT M8 x 1.25
4
--
38
HHB M10 x1.5 x 38 HEX HEAD BOLT M10 x 1.5 x 38
4
--
39 5530114
HHB M8 x 1.25 x 18
4
--
40
HN M10 X 1.5
HEX NUT
4
--
41
10 x 18 x 2.3 LW
SPRING LOCK WASHER
4
--
42
HHB M10 x 1.5 x10
HEX HEAD BOLT
8
--
43 5550103
FTG ELB -04 JIC -06 ORB
1
--
44
90deg.375NPT-.44
90° ELBOW 3/8-18 NPT TO 7/16-20 UNF MALE THREAD
2
--
45
90deg.375NPT
90° ELBOW 3/8-18 NPT TO 3/8-18 NPT MALE THREAD
2
--
46
MALE .25-.4375 TEE
MALE BULKHEAD TEE 1/4"NPT-7/16-20
1/4-18 NPT TO 37° FLARE
7/16-20 UNF 2B
1
--
47
90deg .25 NPT FEMALE-
.4375 MALE
90° ELBOW FEMALE 1/4-18 NPT TO 37° MALE FLARE 7/16-20 UNF 2B 1
3/8" LONG
1
--
48
22 DIA. HAIRPIN COTTER
Ø4.5 x 75mm
6
--
49
P-543
XPR PLASTIC COVER BLOCK 105x80
2
A
50 5730014
XP/XPR-9F/FD/FX/FDX POST ASSEMBLY LIFT HEAD FOOT GUARD R.H.
2
A
51 5730015
XP/XPR-9F/FD/FDX/FX POST ASSEMBLY LIFT HEAD FOOT GUARD L.H.
2
A
52
FG-800420
XP/XPR-9F/9FX BOTTOM SHEAVE COVER
2
A
53
FG-801014
XPR-9F/FD/10C/AC ARM FOOT GUARD (280mm)
2
E
54
FG-801017
XPR-9F/FX/FD/FDX/10C/CX ARM FOOT GUARD (526mm)
2
E
SHEET 1 OF 4
REV
DWG. NO.
A
SIZE
TITLE:
NAME
DATE
CHECKED
DRAWN
SIZE:
MATERIAL:
J
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
PROPRIETARY AND CONFIDENTIAL
THE INFORMATION CONTAINED IN THIS DRAWING IS
THE SOLE PROPERTY OF
BENDPAK INC.
ANY
REPRODUCTION IN PART OR AS A WHOLE WITHOUT
THE WRITTEN PERMISSION OF
BENDPAK INC.
IS
PROHIBITED.
NOTE: UNLESS OTHERWISE SPECIFIED
.
TD
XPR-9-F
XPR-9F LIFT ASSEMBLY
---
---
06/20/2007
DO NOT SCALE DRAWING
--
SCALE:
THIRD ANGLE PROJECTION
AC
01/10/2009
FG-800420,FG-801014,FG-801017,5730014,5730015
1.
& HHB M10 x 1.5 x 10 USED ONLY ON MODELS REQUIRING
FOOT GUARDS.
SEE SHIPPING INSTRUCTIONS FOR FINAL PACKAGING
2.
