48
OFF SIDE SAFETY
DETAIL B
SCALE 1 : 15
POWER SIDE SAFETY
DETAIL C
SCALE 1 : 15
820-1333mm
1255mm
646-
B
3009
3242
3683
2695
DRIVE THRU
C
81-1960.6mm [3.2-77.2"]
140mm [5.5"] ADAPTER
291-2170.6mm [11.5-85.5"]
WITH 70mm [2.75"] &
SHEET 3 OF 4
REV
DWG. NO.
A
SIZE
TITLE:
H
1645 LEMONWOOD DR.
SANTA PAULA, CA 93060
XPR-9-FX
XPR-9FX LIFT ASSEMBLY
1:35
SCALE:
