Setting up the display12
5. Install the wall mounting bracket on the
display and attach the display to the wall
according to the mounting bracket’s
instructions. The length of the screw
should exceed the thickness of the wall
mounting bracket by at least 25 mm.
Make sure that all screws are tightened
and secured properly. (Recommended
torque: 470 - 635N•cm). The mounting
means should be strong enough to bear
the weight of the display.
Thickness of
the wall
mounting
bracket
25 mm
(0.39")
LCD display
• To maintain proper ventilation, keep at least 10 mm of
clear space from the back cover of the display to the
wall.
• Please consult a professional technician for wall mount
installations. The manufacturer accepts no liability for
installations not performed by a professional technician.
