Introduction 9
Projector exterior view
1. External control panel
(See "Projector" on page 10 for
details.)
2. Vent (heated air exhaust)
3. Front IR remote sensor
4. Focus ring
5. Projection lens
6. Multi-input socket
-RGB (PC)/Component video
(YPbPr/ YCbCr) /Composite video/
Audio input (L/R)
7. USB Reader slot
8. Audio output socket (only for USB
Reader)
9. AC adapter inlet
10. Tripod socket
11. Adjuster foot
1
2
3
4
5
Front/upper side
6 7 9
11
8
10
Rear/lower side
