Introduction 11
Controls and functions
Projector
5. ECO BLANK
Press the ECO BLANK button to turn
off the image for a period of time with
70% lamp power saving. See "Hiding the
image" on page 44 for details.
6. AUTO
Automatically determines the best
picture timings for the displayed image.
See "Auto-adjusting the image" on page
28 for details.
7. Power/POWER indicator light
Toggles the projector between standby
mode and on. See "Starting up the
projector" on page 27 for details.
Lights up or flashes when the projector is
under operation. See "Indicators" on
page 89 for detail.
8. TEMPerature indicator light
Lights up red if the projector's
temperature becomes too high. See
"Indicators" on page 89 for details.
9. LAMP indicator light
Indicates the status of the lamp. Lights up
or flashes when the lamp has developed a
problem. See "Indicators" on page 89 for
details.
10. SOURCE
Displays the source selection bar. See
"Switching input signal" on page 36 for
details.
1. MENU/EXIT
Turns on the On-Screen Display (OSD)
menu. Goes back to previous OSD menu,
exits and saves menu settings.
2. Keystone/Arrow keys ( / Up, /
Down)
Displays 2D Keystone page and adjusts the
vertical keystone values. See "Using the
menus" on page 33 for details.
3. Keystone/Arrow keys ( / Left, /
Right)
Displays 2D Keystone page and adjusts the
horizontal keystone values. See "Using the
menus" on page 33 for details.
When the On-Screen Display (OSD) menu
is activated, the #2, and #3 keys are used
as directional arrows to select the desired
menu items and to make adjusents. See
"Using the menus" on page 33 for details.
4. MODE/ENTER
Selects an available picture setup mode.
See "Selecting a picture mode" on page 39
for details.
Activates the selected On-Screen Display
(OSD) menu item. See "Using the menus"
on page 33 for details.
7
6
5
2
8
3
9
10
1
3
4
2
