Operation
72
Description of each menu
• The default values listed in this manual, especially on pages 72-82, are for reference only.
They may vary between the projectors due to the continuous improvement to the
products.
FUNCTION DESCRIPTION
Wall Color
Corrects the projected picture’s color when the projection surface is
not white. See "Using Wall Color" on page 40 for details.
Aspect Ratio
There are four options to set the image's aspect ratio depending on
your input signal source. See "Selecting the aspect ratio" on page 37
for details.
2D Keystone
Corrects vertical and horizontal keystonings of the image. See
"Correcting 2D keystone" on page 28 for details.
Corner Fit
Manually adjust four corners of the image by setting the horizontal
and vertical values. See "Adjusting corner fit" on page 29 for details.
Surface Fit
Manually correct geographic distortion by Surface Fit calibration
function. See "Adjusting surface fit" on page 30 for details.
Position
Displays the position adjusent page. To move the projected image,
use the directional arrow keys. The values shown on the lower
position of the page change with every key press you made until they
reach their maximum or minimum.
This function is only available when a PC signal (analog RGB) is
selected.
Phase
Adjusts the clock phase to reduce image
distortion.
This function is only available when a PC
signal (analog RGB) is selected.
H. Size
Adjusts the horizontal width of the image.
This function is only available when a PC signal (analog RGB) is
selected.
Digital Zoom
Magnifies or reduces the projected image. See "Magnifying and
searching for details" on page 37 for details.
1. DISPLAY menu
