BenQ MX768 - Supported Timing for Hdmi Input

Specifications 95
*
1
Supported timing for 3D signal with Field Sequential, over-under and side-by-side format.
*
2
Supported timing for 3D signal with Field Sequential format.
*
3
Supported timing for 3D signal with over-under and side-by-side format.
There 3D timing showing depend the EDID file and VGA display card. It is possible that user
cannot choose the above 3D timings on VGA display card.
Supported timing for HDMI input
PC timing
Resolution Mode
Ver tica l
Frequency
(Hz)
Horizontal
Frequency
(kHz)
Clock
(MHz)
640 x 480
VGA_60*
1
59.940 31.469 25.175
VGA_72 72.809 37.861 31.500
VGA_75 75.000 37.500 31.500
VGA_85 85.008 43.269 36.000
720 x 400 720 x 400_70 70.087 31.469 28.322
800 x 600
SVGA_60*
1
60.317 37.879 40.000
SVGA_72 72.188 48.077 50.000
SVGA_75 75.000 46.875 49.500
SVGA_85 85.061 53.674 56.250
SVGA_120*
2
(Reduce Blanking)
119.854 77.425 83.000
1024 x 768
XGA_60*
1
60.004 48.363 65.000
XGA_70 70.069 56.476 75.000
XGA_75 75.029 60.023 78.750
XGA_85 84.997 68.677 94.500
XGA_120*
2
(Reduce Blanking)
119.989 97.551 115.500
1152 x 864 1152 x 864_75 75.00 67.500 108.000
1024 x 576
BenQ Notebook
Timing
60.0 35.820 46.996
1024 x 600
BenQ Notebook
Timing
64.995 41.467 51.419
1280 x 720
1280 x 720_60*
1
60.000 45.000 74.250
1280 x 768
1280 x 768_60*
1
59.870 47.776 79.500
1280 x 800
WXGA_60*
1
59.810 49.702 83.500
WXGA_75 74.934 62.795 106.500
WXGA_85 84.880 71.554 122.500
WXGA_120*
2
(Reduce Blanking)
119.909 101.563 146.25
1280 x 1024
SXGA_60*
3
60.020 63.981 108.000
SXGA_75 75.025 79.976 135.000
SXGA_85 85.024 91.146 157.500
1280 x 960
1280 x 960_60*
3
60.000 60.000 108
1280 x 960_85 85.002 85.938 148.500
1360 x 768
1360 x 768_60*
3
60.015 47.712 85.500
1440 x 900
WXGA+_60*
3
59.887 55.935 106.500
1400 x 1050
SXGA+_60*
3
59.978 65.317 121.750
1600 x 1200
UXGA*
3
60.000 75.000 162.000
