Connection 21
Connecting the YPbPr component video input
1. Connect the VIDEO IN (YPbPr) jacks on the display to the component output jacks
on an A/V device (such as a VCR or DVD player) using a component video cable.
2. Connect the DVD player’s audio output jacks to the AUDIO IN (AUDIO2) jacks on
the display using a suitable audio cable.
3. To view video image from this input, press the YPbPr button on the remote
control. To select an appropriate audio source, see Audio Source on page 32 for
details.
The cables are not supplied and should be purchased separately.
DVI-OUT
DVI-IN
HDMI-2
HDMI-1
VGA OUT
VGA IN
Audio cable
DVD player / VCR
Component video cable
