Position the cursor on Sensors L1 then press the ↑ key to view the para-
meters of the Conventional Line. If a valid address is entered the display
will show the relevant data as described in the INSTALLATION MANUAL.
Press the ← or → key to view the parameters of the other Items of the
same type, or press ESC to enter another address (step C).
If an invalid address is entered at step C ,
the display will show the error message
opposite. Press ESC then enter another
address.
Options
This option from the READING PARAMETER menu shows the parame-
ters of the Options.
Select Options from the READING PA-
RAMETER menu (press 2), or press ESC
to step back to the MAIN menu.
The display will show the OPTIONS menu
(see the INSTALLATION MANUAL). Press
ESC to step back to the READING PARA-
METER menu.
Version
The Version option from the READING PARAMETER menu shows the
control panel version.
Select the Version option from the VIEW
PARAMETERS menu (press 3), or press
ESC to step back to the MAIN menu.
The display will show the control panel
version. Press ESC to step back to the
READING PARAMETER menu.
DEVICES LOOP1
Device not
configured
on LOOP 1
READINGS:
1=Dev./Zones/Outputs
2=Opt.3=Ver. 4=Log.
5=Print 6=M.Telecom
RD: OPTIONS
Ø=P 1=W 2=V 3=D 4=T
5=S 6=H 7=D 8=Pulse
9=Extinction Mode
READINGS:
1=Dev./Zones/Outputs
2=Opt.3=Ver. 4=Log.
5=Print 6=M.Telecom
Fire Class 1ØØ
version
3.Ø
EN 54
