B Select the Logger option (press 1) or
press ESC to step back the READINGS
menu.
C
Press the ↵ key to start the Logger Print or
press ESC to quit and step back to B.
D The display will show the message opposi-
te.
+
The control panel will continue functioning during the Logger printout.
Printer not
enabled
The printer must be enabled, otherwise, at
step D the display will show the message
opposite.
Printer not
connected
The serial printer must be connected to the serial port of the control panel.
The control panel will ignore the fact that no printer is connected, or that
the connected printer is not ready (paper out, no ink or blocked etc.). To
stop the Print follow the instructions below.
Stop Print To stop Print - proceed as per start Print.
At step C (when the ↵ key is pressed) the
display will show the message opposite.
Press the ↵ key to stop the Print or press ESC to step back to C.
Print
Programming
The Programming option from the PRINT menu is reserved for future use.
If the Programming option is selected
from the PRINT menu (key 2) ...
READINGS
Print:
1= Logger
2= Programming
Logger Print
Start Print ?
Enter = Yes
Esc = Exit
Logger Print
running
please
wait....
Printer not
enabled !
Enable in
menu’ PRG:SYSTEM
Logger Print
running
stop ?
Yes = Enter
READINGS
Print:
1= Logger
2= Programming
READING PARAMETER 31
