Bentel Security KYO 4 M User Manual

16
Multifunction Control Panel
®®
Table 2.1 - Identification the Main Unit Parts
Part Description
1 Frontplate Screws (2)
2 Locations (4) for backplate screws (Ø = 5 mm)
3a Reverse locking PCB supports (see Figure 3.3)
3b PCB location Tabs
3c Locations (2) for PCB screws
3d Arrester for BAQ35T12 Switching Power-Supply/Battery Charger
3e 13 mm plastic support
4 Terminal Board
5 DB-9 male connector for computer link
6 BPI Level Jumper:
12V
k
5V
 5 V (at default);
12V
j
5V
 12 V
7 Firmware Release label
8
Stop Alarm Jumper: Open ( )  Alarms Uninhibited (default);
Stop Alarm Jumper: Closed (K)

Alarms Inhibited
9a BATT Fuse: F8A - 250V
9b BPI Fuse (Fuse — protects BPI Bus [+] terminal): F2A - 250V
9c
+B Fuse: F5A - 250V (K4, K8, K8W and K32 boards)
+F Fuse: F5A - 250V (Only for 'G' boards)
9d Reserved Jumper
9e Auxiliary Connector for BPI Devices (K8G, K8GW, K32 and K32G boards ONLY)
10 Connector for Tamper and Snatch Microswitches (N.O. at default)
11a Tamper Microswitch for BOX-P (A ccessory Item, code A SNC)
11b Tamper Microswitch for BOX-M and BOX-L (Accessory Item, code MAXI-ASNC)
11c On-Board Tamper Microswitch (Only for 'G' PCBs)
11d Plastic spacers (2): inside the MAXI-ASNC Tamper Microswitch package
11e Snatch Microswitch (Accessory Item)
11f Snatch Microswitch bracket
11g
Jumper for on-board Tamper-Microswitch [11c]:
Open (J)  Microswitch disabled,
Closed (K)  Microswitch enabled (at default)
12a Optional Voice Board (Order Code: NC2/VOX — refer to Section 5)
12b Voice Board Holder
13a Earth Wire
13b Earth Wire on PCB - terminal (L=400 mm)
13c Earth Wire on PCB - terminal (L=120 mm)
14 Power Transformer — 220-17Vac-1.5A (Order Code: TRF)
15 Battery wires
16 Cable supports
17 Cable entry
18a Marking ticket
18b Release Label
