16
Bentone BF1
General
D
3.1.7 Rotation of the air intake
The air intake of the burner can be rotated, although the rotation options are
limited due to the two-stage control. In principle it is possible to install the air
intake pointing upwards. It is also possible to rotate the air intake so that the
burner can be adapted to different environments.
To rotate the air intake, loosen the three screws holding the air intake and
the two screws holding the pump. Depending on how much the air intake
is to be rotated, cabling will be required and the two-stage control must be
removed. Then rotate the air intake to the desired position and tighten the
screws. Where appropriate, fit the cabling and two-stage control in a position
which allows for adjustment. When changing to certain positions on the air
intake, the screw for the air control must be removed and then fitted in a
position which allows the air to be adjusted.
The position of the air intake affects the air flow through the burner
somewhat. The position that provides maximum flow is with the air intake
pointing downwards.
3.1.8 Air duct
A hose connection air duct is available in three different dimensions: 48, 68,
and 78 mm outer diameter (D). The air duct is installed on the air intake at
the place where the grille is attached in the standard model
