Bentone BF1 Series - Technical Data for Burner Controls

35 Bentone BF1
General
7.1.3 Technical data
LMO24 LMO44 LOA24
Pre-ignition period:
25 s 25 s 13 s
Pre-ventilation period:
26 s 26 s 13 s
Post-ignition period:
5 s 5 s 15 s
Safety period:
< 5 s < 5 s < 10 s
Re-connection after release:
< 1 s < 1 s < 50 s
Reaction time flame extinction:
< 1 s < 1 s < 1 s
Ambient temperature:
-20 - +60°C -20 - +60°C -20 - +60°C
Min. current with flame:
45 µA 45 µA 65 µA
Max current when dark, start:
5,5 µ A 5,5 µA 5 µA
Ingress Protection:
IP 40 IP 40 IP 40
LOA not to be used within EU
Photocell current checks
Photocell current is measured with a direct current ammeter
(mulitimeter μA) connected in series with the photocell.
