Bentone BF1 Series - Model BF1-2 K 76-26 Specifications; Burner Output and Basic Settings

7 Bentone BF1
General
!
Scale value applies to 0 mbar furnace pressure.
ø70
ø26
ø76
8,0-9,0
2,7-3,3
0,5-1,5
Boiler overpressure, mbar
Burner output, kW
-0,5
0,0
0,5
1,0
1,5
2,0
2,5
3,0
3,5
4,0
40 45 50 55 60 65 70 75 80 85 90 95 100 105
Scale
Burner output, kW
0,0
2,0
4,0
6,0
8,0
10,0
12,0
14,0
16,0
18,0
20,0
22,0
25 30 35 40 45 50 55 60 65 70 75 80 85 90 95 100
Stage 1
Stage 2
Nozzle assembly
1.2 Model BF1-2 K 76-26
Length of blast tube
Protrusion from ange, measurement B
Flange
1 2 3 4
117 82 95 103 102
147 112 125 133 132
197 162 175 183 182
1.2.1 Burner output/ Basic settings
3,8 - 8,4 kg/h
45 - 100 kW
