Bentone BF1 Series - Nozzle and Pressure Recommendations; Burner with Preheater Details

8
Bentone BF1
General
1.3 Recommended nozzles and pressures
Because of the different types of boiler in existence, with varying furnace
geometries and furnace loads, it is not possible to commit to any given spray
angle or spay pattern. Note that spray angles and spray patterns change
with pump pressures.
1.3.1 Burner with preheater
Allow for a reduction in oil quantity of 5–20% with preheating owing to:
• Temperature increases at the nozzle.
• Nozzle design.
• Capacity (the higher the capacity the lower the difference).
Pump pressure, bar
Gph 8 10 12 14 16 18 20 22 23 24
kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW kg/h kW
0,40 1,33 16 1,49 18 1,63 19 1,76 21 1,85 22 1,96 23 2,06 25 2,17 26 2,21 27 2,26 27
0,50 1,66 20 1,86 22 2,04 24 2,20 26 2,37 28 2,51 30 2,64 31 2,77 33 2,84 34 2,90 34
0,60 2,00 24 2,23 26 2,45 29 2,64 31 3,00 36 3,18 38 3,35 40 3,52 42 3,59 43 3,67 44
0,65 2,16 26 2,42 29 2,65 31 2,86 34 3,38 40 3,58 43 3,78 45 3,96 47 4,05 48 4,14 49
0,75 2,49 29 2,79 33 3,08 36 3,30 39 3,72 44 3,94 47 4,16 49 4,36 52 4,46 53
4,55 54
0,85 2,83 33 3,16 37 3,47 41 3,74 44 4,19 50 4,44 53 4,68 56 4,91 58 5,02 59 5,13 61
1,00 3,33 39 3,72 44 4,08 48 4,40 52 4,71 56 4,99 59 5,26 62 5,52 65 5,64 67 5,76 68
1,10 3,66 43 4,09 48 4,48 53 4,84 57 5,36 64 5,69 67 6,00 71 6,29 75 6,43 76 6,57 78
1,20 3,99 47 4,47 53 4,89 58 5,29 63 5,63 67 5,97 71 6,29 75 6,60 78 6,75 80 6,89 82
1,25 4,16 49 4,65 55 5,10 60 5,51 65 5,96 71 6,32 75 6,66 79 6,99 83 7,14 85 7,30 86
1,35 4,49 53 5,02 59 5,50 65 5,95 70 6,54 78 6,94 82 7,31 87 7,67 91 7,84 93 8,01 95
1,50 4,98 59 5,58 66 6,11
72 6,60 78 7,39 88 7,84 93 8,26 98 8,66 103 8,86 105 9,05 107
1,65 5,49 65 6,14 73 6,73 80 7,27 86 7,69 91 8,16 97 8,60 102 9,02 107 9,22 109 9,42 112
1,75 5,82 69 6,51 77 7,14 85 7,71 91 8,29 98 8,79 104 9,26 110 9,72 115 9,93 118 10,15 120
2,00 6,65 79 7,45 88 8,18 97 8,81 104 9,39 111 9,95 118 10,49 124 11,01 131 11,25 133 11,50 136
2,25 7,49 89 8,38 99 9,18 109 9,91 117 10,56 125 11,20 133 11,81 140 12,39 147 12,66 150 12,94 153
The table applies to oils with a viscosity of 4.4 mm
2
/s (cSt) at a density of 830 kg/m
3
.
1.4 Nozzle table, 8-24 bar
Nozzle 60° Solid/Hollow cone
80° Solid/Hollow cone
Pump pressure: Fuel oil 1 8 - 24 bar
1-stage 10 bar (8 - 12 bar)
2-stage 20 bar (15 - 24 bar)
Pump pressure: Kerosene 8 - 12 bar
1-stage 9 bar (8 - 10 bar)
2-stage 11 b ar (10 - 12 bar)
