21.12.98 Operating manual
04_GB ACP 3000 — 0.37–15.0
7
Berges electronic • D–51709 Marienheide-Rodt • Tel. 02264/17-0 • Fax 02264/17126
2.3 General Drive Specifications
Inverter
Power Ratings
Input Frequency 50/60 Hz (±2%)
Phase Imbalance (3 ∅ only) ±2%
Overload Capacity 150% for 60 seconds
Running Torque 100% at 3 Hz
Starting Torque Greater than 100%
Control
Specifications
Control System Sine-weighted voltage vector (PWM)
PWM Frequency 4–16 kHz (plus Autoselect feature)
Frequency Range 1.00–400.0 Hz programmable in 0.05 Hz increments
(0.1 Hz above 99.95 Hz)
Frequency resolution 0.05 Hz up 0.00 to 99.95 Hz,
0.1 Hz above 100.0 Hz
Minimum Frequency 0.00–400.0 Hz
Maximum Frequency 20.00–400.0 Hz
Preset Speeds Up to 8 available; programmable to maximum frequency
Frequency Command
Selections
0–5 VDC, 0–10 VDC, 0–20 mA, 4–20 mA, direct or inverted;
Digital Keypad; Program Memory Unit; Remote Keypad Unit;
external Potentiometer
Acceleration and Deceleration
Range
Programmable 0.1 to 600 seconds to maximum frequency
(2 Each)
V/Hz Ratio 0.19–9.23 V/Hz (230 VAC models)
0.39–18.46 V/Hz (400 VAC models)
Torque Limit Automatic or fixed adjustment possible
Dynamic Braking Up to 60% for 6 sec. with standard DB resistor; higher braking
power values can be achieved by means of an external braking
chopper (option)
Protection
Features
Ground Fault Protected from damage
Short Circuit Protected from damage
Motor Overload Programmable inverse time overload trip
Torque Limit All four quadrants individually programmable
Overvoltage Short voltage peaks are bridged; an error is triggered if an ov-
ervoltage lasts for longer than 500 ms
Undervoltage Short voltage dips are bridged; a defined “Restart” is performed
if an undervoltage lasts for longer than 200 ms
Over Temperature Protected from damage, warning display
MOL Input Terminal Programmable for N.C. or N.O. contacts
Operating
Features
Operating Controls 1. Keypad.
2. Remote keypad unit.
3. Terminal strip.
4. Program memory unit.
