NOTES:
1) VIN1/VIN2 changeover via PS3.
2) Data codes 6 up to 9 select the ACP EMOP control programs. With codes 6 or 7 (EMOP)
selected, commanded output frequency returns to
31-FMIN when the drive is stopped.
With codes 8 or 9 (EMOP1) selected, commanded output frequency remains at the pre-
vious setpoint. See table above for proper usage.
◊ Value range: 0–11 Default: 3
EMOP/EMOP1 Control Terminal Logic Table
(Electronic Motor Potentiometer)
DATA
CODE
SPEED CONTROL START/STOP CONTROL
0 Keypad Keypad (FWD only)
1
VIN Terminals
1)
Keypad (FWD only)
2 Keypad Terminals (2-Wire Maintained Contact)
3
VIN Terminals
1)
Terminals (2-Wire Maintained Contact)
4 Keypad Terminals
(3-Wire Momentary, RUN/JOG via PS3)
5 VIN Terminals Terminals
(3-Wire Momentary, RUN/JOG via PS3)
6
EMOP
2)
(Electronic motor potentiometer)
Terminals
(2-Wire, see section 7.7, page 61 and table below)
7
EMOP
2)
(Electronic motor potentiometer)
Terminals
(3-Wire, see section 7.7, page 61 and table below)
8
EMOP1
2)
(Electronic motor potentiometer)
Terminals
(2-Wire, see section 7.7, page 61 and table below)
9
EMOP1
2)
(Electronic motor potentiometer)
Terminals
(3-Wire, see section 7.7, page 61 and table below)
10 Keypad Keypad (FWD and REV)
11
VIN Terminals
1)
Keypad (FWD and REV)
DESCRIPTION FWD REV PS1 PS2
STOP 00XX
Speed = 0 11XX
FWD Decrease 101X
FWD Hold 1000
FWD Increase 1001
REV Decrease 011X
REV Hold 0100
REV Increase 0101
0 = inactive 1 = active X = ignored
