Berges electronic • D–51709 Marienheide-Rodt • Tel. 02264/17-0 • Fax 02264/17126
Operating manual 21.12.98
ACP 3000 — 0.37–15.0 04_GB
50
◊ Value range: 0–3000 Default: 0
Entering a number between 1 and 999 provides controlled access to program parameters
(both Level 1 and Level 2). After an access code has been entered, the initial display will
indicate:
After an access code has been entered, the user must enter that number to be allowed to
re-program any parameter. If the wrong number is entered, all parameters can be viewed
but not changed. Consult factory for over-ride code if access code has been lost. Access is
allowed for 10 minutes after the last keystroke or until the drive goes through a restart se-
quence. Press the PROG key twice within two seconds after programming to immediately
re-instate the access code.
◊ Value range: 0–999 Default: 0
This parameter displays the secondary software revision level.
◊ Value range: 0.00–12.75
DATA
CODE
BESCHREIBUNG
0 Output Frequency in Hz (value of
12-FOUT
).
1 Output Current in Amps (value of
14-IOUT
).
2 Drive Load in percent (value of
15-LOAD
).
3 FSTAT (stator frequency); see
71-METER
for definition.
3–3000 Display indicates rpm. The rated speed of the motor is multiplied by 20 and di-
vided by the rated frequency for calculation. The result is the data code to be
set, e.g.:
NOTE: Data Code must be rounded to nearest whole number.
87-ACODE – Security Access Code 2P
97-RVLVL2 – Software Revision Level 2 2V
1500 rpm 20×
50 Hz
-------------------------------------- 600=
