Irrigation IOM
Sensors
| 15 |
Insertion sensors
15 DN
10 DN
Fig. 14 Installation on U-shaped tube
T” connection downstream of the flowmeter
10 DN
Fig. 15 Installation on U-shaped tube
Three-dimensional curves
10 DN
Fig. 16 Installation near three-dimensional bends
