Rev 9 2022
35
Maintenance & Repair Tape Sensor (ESA Only)
Part Numbers
• E55506901
Tools Needed
• Philips head screwdriver
• Zip cable e
Procedure
1. Unplug Machine
2. Remove the water bole, and tank assembly
3. Remove le side cover (5 Philips screws) be careful as the ribbons connecng the keypad can be ripped easily.
4. Unplug keypad ribbons from controller board
5. Remove sensor from heater assemble it should twist and pull out
6. Remove connector from controller board
7. Cut cable e
8. Remove old sensor
9. Snap new sensor into place on back of heater assembly
10. Run wire to controller board
11. Plug into controller board
12. Use cable e to secure wire to machine
13. On le cover plug keypad ribbons back into controller board
a. Be sure not to miss any pins as this will eect the length selected
14. Reinstall le cover be sure not to pinch or drive a screw through the keypad ribbons.
15. Replace water tank, brushes, and water bole
