26
Rev 9 2022
Maintenance & Repair Thermostat Replacement
It is recommended that the heater parts be replace with a Beer Packages supplied heater parts to maintain safety
compliance.
If the heater is no longer funconing and the heater plates are clean and well maintained replacing the thermostat will
most likely x any heang issues.
When replacing the heater it is customary to also replace the blade oiler and feed wheel as they are wear items and
the machine will be disassembled enough to conduct those replacements at the same me.
Part Numbers
• ST2313 – Thermostat
Tools needed
• Philips head screwdriver
• Flat head screwdriver
• 5/16” Nut Driver
Procedure
1. Unplug Machine
2. Remove the water bole, and tank assembly
3. Remove right side cover (5 Philips screws)
4. Remove le side cover (5 Philips screws) be
careful as the ribbons connecng the keypad can
be ripped easily.
5. Unplug keypad ribbons from controller board
6. Unplug the heater from the controller board
7. Cut any es that are holding down the wires for
the heater
8. Loosen screw on the upper right side of frame
holding the retainer bracket
9. From the right side remove the sha holding the
heater assembly in place
10. Remove the heater and lower heat plate
11. Place the heater on a at surface and remove
the cap on the control knob (using a at head
screwdriver or razer knife if needed)
To Next Page
