22 BC615 Installation and User Manual
1
Power LED. Lit green when CR1 is powered.
2
RX. Yellow LED flashing quickly when CR1 is communicating
with the PC.
3
TX/RTS. Flashes green/red when CR1 is communicating with the
card reader.
4
Power supply to card reader. Connect to terminal nos 1 and 2 on the
BC615 circuit board.
5
Communication between CR1 and card reader. Connect TX to TX,
RX to RX, RTS to ENAB and 0V to 0V.
6
Connection to the next dropbox or SR32i in Entro system.
Note! Fit 120 ohm resistor between the A and B of the communications in
the CR1 unit at the each end of the line .
