Bewator BM3 - Control and Input Terminals; Output and Power Terminals

BM3 Installation & User Manual 13
ENG
1
SW1 push button. Used to set the pass-
word and erase the memory.
2
Connection to the telephone system.
3
Exit button. Connect terminal nos 12 and
13. Looped = door open.
4
Time control from the external time clock.
Input 1: Connect terminal nos 11 and 13.
Input 2: Connect terminal nos 10 and 13.
Looped input = the codes are disabled.
5
Camera relay output.
6
Tamper switch. Normally closed when the
housing is closed.
7
Power supply in, terminal nos 1 and 2.
8
Electric locking device. Dashed line refers
to locks with failsafe function.
9
Speaker volume.
10
Microphone sensitivity.
11
Jumper for 12 or 24 V voltage supply. If
above 20 V, set the jumper to 24 V.
