Beyerdynamic SIS - Page 44

SIS 1202 Interpreter Station
44
Right Side of the Interpreter Station
Card reader
Network output (to connect to the next interpreter station)
Network input (to connect to the control unit or the previous interpreter station)
Microphone input with 12 V phantom powering to connect a microphone
Headphone connection 6.35 mm jack (1/4")
Headphone connection 3.5 mm jack (1/8"), also for the connection of a recorder
Left Side of the Interpreter Station
, - same as above
Connection for power supply unit
16
17
18
19
20
21
16
22
19 21
16
1718
19
20
21
16
22
19
20
21
