Set up
58
Application with SIS Interpretation System and MCW-D Wireless, Digital Conference System (3 + 1)
Required Components:
1 x MCW-D 200 Control unit
2 x CA 3125 Cables to connect the MCW-D 200 control unit to the SIS 121 control unit
1 x MCW-D 2073 Chairman station with display and headphone to listen to the foreign languages
several MCW-D 2071 Delegate stations with display and headphones to listen to the foreign languages
1 x SIS 121 Control unit
3 x SIS 1202 Interpreter stations
1 x CA 3110 CAT.5 cable, 10 metres
2 x CA 3105 CAT.5 cables, 5 metres
6 x DT 394.SIS Headsets
Connection
Connect the DAN In input of the first interpreter station to the DAN connection of the SIS control unit. Connect the DAN Out
output of the first interpreter station to the DAN In input of the second interpreter station and so on. Use e.g. the CA 3110 cable
(10 metres long) to connect the first interpreter station to the control unit. To connect the interpreter stations to one another use e.g. the
CA 3105 cable (5 metres long). Connect the DT 394.SIS headset to the interpreter stations.
18
17 18
8
