INTRODUCTION COMFORT AIR CURTAIN
8
-CA
2
W: Water-heated models;
-CA
2
E: Electrically-heated models;
-CA
2
F: Free-hanging models.
Note:
n In the illustrations in this manual, the following unit type is
used as a general example: CA2 M-150-W-F. The
a
ppearance of your unit may be different but its function is
the same, unless stated otherwise.
Table 1-2 Ex
planation of the type code
P
ART TYPE CODE DESIGNATION MEANING
Product series CA
2
General reference for the series
Daikin system V For connection to Daikin VRV system (‘mu
lti’)
Q For connection to Daikin ERQ system (‘pai
r’)
Capacity S, M, L or XL Small, medium, large or extra large range
Discharge width 100, 150, 200 or 250 Discharge width in cm
Heating W Water heating
E Electric heating
A Without heating
DK Heating with Daikin direct expansion system
Mounting method F Free-hanging model
R Recessed model
C Cassette model
Valve (only CA
2
W) 2-way Two-way valve installed instead of a three-way valve.
Colour (only CA
2
V
and CA
2
Q)
B white
S aluminium
X non-standard colour
Control panel (only
CA
2
V and CA
2
Q)
C B-touch control panel included
N Not included (if several units are connected in one
instal
lation)
