BIFFI ALGAS User Manual

8
Ø d
1
max
Ø d
4
h
2
Ø d
2
+0.1
0
Ø d
3
±0.2
h
1
+0.5
0
H max
Ø d
5
+0.2
+0.1
K
+0.4
0
W
D10
18 680 290 603 M36 16 12 32 350 200 45 220.8
32 780 290 603 M36 16 12 32 400 220 50 242.8
35 780 315 603 M36 16 11 32 400 240 50 242.8
42 840 310 603 M36 16 12 32 400 220 50 242.8
MAN 604A Rev. 5
Installation
Section 2: Installation
Dimensions in millimeters
Actuator model Ø d
1
Ø d
2
Ø d
3
Ø d
4
N h
1
h
2
H max Ø d
5
W K
Figure 5
Drive sleeve
N. THREADED HOLES
PCD, holes, number and
size according to ISO 5211
Top view of the scotch yoke mechanism
(actuator shown in closed position)
Flow line
June 2020
Installation, Operation and Maintenance Manual
Table 5.
