BIFFI FAIL SAFE ELECTRIC ACTUATORS, MODEL EFS2000V4
InstructIon and operatIng Manual
PST Set-up
• Press YES if the parameter ‘PST mode’ is
correct, press NO to scroll through the list of
available values. Press YES when the value is
correct.
• Press YES if the parameter ‘SPRING ACTION’
is correct, press NO to change. Press YES
when the value is correct.
• Press YES if the parameter ‘PERIOD’ is
correct, press NO to scroll through the list of
available values. Press YES when the value is
correct.
• Press YES if the parameter ‘HOUR of DAY
PST’ is correct, press NO to scroll through
the list of available values. Press YES when
the value is correct.
• Press YES if the parameter ‘PST TRAVEL’ is
correct, press NO to scroll through the list of
available values. Press YES when the value is
correct.
• Press YES if the parameter ‘MAX T-PST’ is
correct, press NO to scroll through the list of
available values. Press YES when the value is
correct.
• Press YES if the parameter ‘MAX PST T-RET’
is correct, press NO to scroll through the list
of available values. Press YES when the value
is correct.
• Press YES if the parameter ‘PAUSE’ is
correct, press NO to scroll the list of available
values. Press YES when the value is correct.
• Press YES if the parameter ‘MAX PST OV-TR’
is correct, press NO to scroll through the list
of available values. Press YES when the value
is correct to return to PST SETUP.
• Press NO to return to EFS SETUP. Press NO
to move to next routine.
13.1.4 Remote controls
The actuator may be remotely controlled by 4,
or 3, or 2 wires depending on the connection
made on the terminal board of the actuator.
The following options are available:
• 4 wires latched: requires 2 momentary
signals (since the control is self-maintained)
to open or close and one signal to stop in
mid-travel. The action of the stop signal can
be reversed (stop when signal is ON (MAKE)
or stop when signal is OFF (BREAK).
• 3 wires latched instant reverse: requires
2 momentary signals (since the control is
self-maintained) to open or close. Reverse
momentary signal reverses the direction.
• 3 wires momentary: requires 2 push-to-run
type signals (since the control is not self-
maintained) to open or close
• 2 wires open if signal On: requires signal On
to open and no signal to close
• 2 wires open if signal Off: requires signal Off
to open and signal On to close
13.1.5 Local controls
This routine allows:
• To configure the control mode by means
of the local controls when the 3-position
selector is in LOCAL. The available options
are ‘push-to-run’, ‘latched’, ‘latched with
instant reverse’.
• To set the LED’s color. The following options
are available: open LED: green or red; close
LED: green or red; alarm LED: yellow or red.
Configuration procedure
• Move the local selector to OFF and then
simultaneously press OPEN and STOP within
20 sec (see chapter ‘Local controls, entering
the set-up mode’). Select the language and
then enter the password according to the
instructions (see ‘Entering the set-up mode’).
When the message displayed is ‘SET-UP
MODE OK?’ press YES. Press YES to select
the actuator set-up menu, press NO to scroll
the list of available routines and then press
YES to select Local controls.
• Press YES to change control mode, or press
NO to proceed to LED’s color setting.
By selecting the option ‘Off’, the remote
controls are disabled.
Configuration should be done during actuator
set-up.
Setup procedure
• Move the local selector to OFF and then
simultaneously press OPEN and STOP within
20 sec (see chapter ‘Local controls, entering
the set-up mode’). Select the language and
then enter the password according to the
instructions (see ‘Entering the set-up mode’).
When the message displayed is ‘SET-UP
MODE OK?’ press YES. Press YES to select
actuator set-up menu, press NO to scroll the
list of available routines and then press YES
to select Remote controls.
• Press YES if the control mode is correct
or NO to scroll the list of available options:
4 wires, 3 wires, 2 wires, off. Press YES to
select the desired option. If 4 wires were
chosen use YES and NO to select the STOP
signal: set MAKE to stop when signal is on
and set BREAK to stop when signal is off. If ‘3
wires’ was chosen, use YES or NO to answer
the prompt on the display and choose among
‘push-to-run’ or ‘latched instant reverse’
control modes. If ‘2 wires’ was chosen, use
YES and NO to choose among ‘open if signal
ON’ or ‘open if signal OFF’ control modes.
