BIFFI FAIL SAFE ELECTRIC ACTUATORS, MODEL EFS2000V4
InstructIon and operatIng Manual
14 VIEW ROUTINES
14.1 Actuator set-up
The above menu allows viewing the present actuator configuration. No change can be made to the
present data. The following data can be viewed:
Routine Parameters
• Stroke limits • Close limit type (torque or position), open limit type (torque or position)
• Torque set-up • Closing torque limit %, opening torque limit %
• EFS setup • EFS and PST parameters
• Remote controls • Control type
• Local controls • Control type, LED’s color
• Output relays • Monitor relay conditions, ASi conditions, contact action
• Positioner* • Dead band, motion inhibit time, polarity, %min, %max (%min and %max are present
only if ‘position request R%’ is from 4-20 mA input)
• Failsafe* • Action, delay
• Out 4-20 mA* • Output signal (position or torque), polarity
• Interlock • Signal type in OP, signal type in CL
• 2-speed timer • Close direction: status, start, stop, on time, off time
• Open direction: status, start, stop, on time, off time
• Bus* • Node address, terminations, etc. depending on fieldbus type
• Miscellaneous • Time and date, torque mode, lithium battery, torque by pass %, valve jammed time
14.2 Name plate
Use this menu to view the data identifying the
actuator. The data are entered in-house and
can only be changed by the manufacturer. The
following data may be viewed:
• Serial number: max. 28 characters, univocal
identifier of the actuator by reference to BIFFI
acknowledgment.
• Actuator type: max. 28 characters, describes
the type of actuator with reference to BIFFI
catalog.
The routines with * can only be viewed if the
relevant electronic cards are present. If the bus
interface is LonWorks, routine ‘Bus’ changes to
‘FDI control’.
Detailed descriptions of the above routines and
their parameters can be found in Chapter ‘Set-
up routines’/
View procedure
• Move the local selector to OFF and then
simultaneously press OPEN and STOP within
20 sec (see chapter ‘Local controls, entering
the set-up mode’). Select the language
according to the instructions (see ‘Entering
the set-up mode’). When the message
displayed is ‘SET-UP MODE OK?’ press YES.
Press YES to select the Actuator set-up
menu.
• Press NO to scroll through the list of available
routines and press YES to select.
• Press YES to answer at the prompt ‘view’ or
‘next’ and to see the data.
• Torque/thrust: nominal torque or thrust of
actuator
• Actuator speed: nominal speed of actuator.
• Power supply: nominal voltage and frequency
of actuator.
• Motor data: includes the following data
relevant to the electrical motor:
• Power type (3ph, 1ph, dc).
• Power rating, max. 99.9 KW.
• In, max. 99.9 A.
• Is, max. 99.9 A.
• Icc, max 999.9 A.
• Duty (S2/15 min, etc.).
• Poles (2, 4, etc.).
• Biffi name, max 28 characters.
• Gear ratio, max 1000.
• Test date: date of the in-house functional
testof actuator.
• Wiring diagram (WD): wiring diagram
number, max 28 characters.
• Enclosure: type of enclosure (Eex-d, etc),
max28 characters.
• Certificate: number of certificate, max. 28
characters.
• Lubricant: type of lubricant, max. 28
characters.
• Revision: HW revision of base card, SW
revision of H8 microprocessor, SW revision
ofPIC microprocessor.
• Torque sensor: data relevant to the
relationship between motor torque and
speed. This set of data contains also the
factory torque limit setting, ‘Torque-set CL’
and ‘Torque-set OP’.
