BIFFI EFS2000v4 - View Menu

27
BIFFI FAIL SAFE ELECTRIC ACTUATORS, MODEL EFS2000V4
InstructIon and operatIng Manual
Display
Local
Off
Remote
Yes
Stop
No
Select
language
To set-up menu
To exit from VIEW menu, press YES or NO
simultaneously or move the 3-position
selector to LOCAL or REMOTE
Routines with * are available only if the
relevant module was enabled.
Routine:
• Stroke limits view?
• Torque set-up view?
• ESD set-up view?
• Remote control view?
• Local control view?
• Output relays view?
• Positioner view?
• Failsafe view?
• Output 4-2 mA view?
• Interlock view?
• Miscellaneous view?
Routine:
• Serial number view?
• Actuator type view?
• Trust/Torque view?
• Actuator speed view?
• Power supply view?
• Motor data view?
• Test date view?
• Wiring diagram view?
• Enclosure view?
• Certificate view?
• Lubricant view?
• Revision view?
Routine:
• Tagname view?
• Serial number view?
• Manufacturer view?
• Break-OP torque view?
• Break-CL torque view?
• Max stem trust view?
• Flange type view?
Routine:
• Alarm log view?
• Torque profile view?
• Torque curve view?
• Operation log view?
• Maintenance date view?
• Data log config. view?
Press YES or NO to answer at the appropriate prompts (OK? view? next? etc.)
3-position selector
From enter password
routine
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
No
No
No
No
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Stroke limits
routine
Tagname
routine
Set password
routine
Routine
xxxxxxx
Routine
xxxxxxx
Routine
xxxxxxx
Miscella-
neous
Flange type
routine
Set ESD
reference
routine
12 VIEW MENU
The below figure shows the procedure to move in the view routine .
No
No
No
No
No
No
No
Yes
Yes
Yes
Yes
Yes
