value between 20 and 1000. A beacon is a packet broadcast by the Router to synchronize the wireless
network.
RTS/CTS Threshold: The RTS (Request To Send) threshold (number of bytes) for enabling
RTS/CTS handshake. Data with its frame size larger than this value will perform the RTS/CTS
handshake. Setting this attribute to be larger than the maximum MSDU (MAC service data unit) size
turns off the RTS/CTS handshake. Setting this attribute to zero turns on the RTS/CTS handshake.
Enter a value between 1500 and 2347.
Fragmentation Threshold: The threshold (number of bytes) for the fragmentation boundary for
directed messages. It is the maximum data fragment size that can be sent. Enter a value between 256
and 2346.
DMIT: This value, between 1 and 255, indicates the interval of the Delivery Traffic Indication
Message (DTIM).
Wireless Mode: The default setting is 802.11b+g+n (Mixed mode). If you do not know or have both
11g and 11b devices in your network, then keep the default in mixed mode. From the drop-down
manual, you can select 802.11g if you have only 11g card. If you have only 11b card, then select
802.11b and if you only have 802.11n then select 802.11n.
11n Settings
Channel Bandwidth: Select either 20 MHz or 20/40 MHz for the channel bandwidth. The higher
the bandwidth the better the performance will be.
Guard Interval: Select either 400nsec or 800nsec for the guard interval. The guard interval is here
to ensure that data transmission do not interfere with each other, it also prevents propagation delays,
echoing and reflections.
MCS: There are options 0~15 and AUTO to select for the Modulation and Coding Scheme. We
recommend users selecting AUTO.
SSID Settings
SSID Index: Default SSID index is “1”.
Broadcast SSID: Select Yes to make the SSID visible so a station can obtain the SSID through
passive scanning. Select No to hide the SSID in so a station cannot obtain the SSID through passive
scanning.
WMM: WMM (Wi-Fi Multimedia) is a simple QoS which prioritizes traffic based on 4 AC (Access
Categories) voice, video, best effort and background but it does not provide a guarantee throughput.
Choose Enable to activate the function or else leave it as Disable.
Note: When you select one of 802.11n/802.11g+n/802.11b+g+n in the Wireless mode of Access
Point Settings section, the WMM function will not exist, that is to say this function is invalid.
40
