2.1 Chamber overview
Figure 3: Cooling incubator KB 23
(1) Main power switch on/off
(2) Temperature controller RD3
(3) Instrument box
(4) Chamber door
(5) Refrigerating module
2.2 Control panel
(2) (6) (1)
Figure 4: Control panel
(1) Main power switch on/off
(2) Program controller RD3
(2)
(1)
(4)
(3)
(5)
