Binder KB 23 - Equipment and Options (Extract)

KB 23 / KB 23-UL (E3.1) 02/2019 page 73/87
Different electrical data for KB 23-UL constructed for the USA and Canada
Nominal voltage (±10%) at 60 Hz power frequency
V
115
Power plug
NEMA
5-15P
Chamber fuse 6,3 x 32 mm, 250V, super-time-lag TT,
external
Amp 12.5
Additional temperature fuse, internal
class 1 (DIN 12880)
Environment-specific data
Energy consumption
at 5 °C
Wh/h
50
at 40 °C
Wh/h
60
Filling weight of refrigerant R 134A (GWP 1300)
Kg / lbs
0.075
All technical data is specified for unloaded chambers with standard equipment at an ambient temperature
of +22 °C +/- 3°C / 71.6 °F +/- 5.4 °F and a power supply voltage fluctuation of +/-10 %. Technical data is
determined in accordance to BINDER Factory Standard Part 1:2015 following DIN 12880:2007.
All indications are average values, typical for chambers produced in series. We reserve the right to
change technical specifications at any time.
If the chamber is fully loaded, the specified heating up and cooling down times may vary
according to the load.
20.5 Equipment and Options (extract)
To operate the cooling incubator, use only original BINDER accessories or accessories /
components from third-party suppliers authorized by BINDER. The user is responsible for any
risk arising from using unauthorized accessories.
Regular equipment
RD3 Multifunction program controller with digital display
Temperature safety controller class 3.1 acc. to DIN 12880:2007
Communication interface RS 422
Inner glass door
DCT™ refrigerating system with refrigerant R134a
Options / accessories
Additional access ports 10 mm / 0.39 in / 30 mm / 1.18 in or 50 mm / 1.97 in with silicone plug
Rack lockings (4 pc.)
Additional shelf, stainless steel
Rubber pads for safe stacking (4 pieces)
Data Logger Kit T 220
Lockable door
Factory calibration certificate
Spatial temperature measurement with certificate
Qualification folder
