KB 23 / KB 23-UL (E3.1) 02/2019 page 7/87
1.4 Type plate
The type plate is located behind the outer door, bottom left-hand.
Figure 2: Type plate (example of KB 23 (230 V) regular chamber)
Indications of the type plate
(example)
Information
BINDER
Manufacturer: BINDER GmbH
KB 23
Model designation
Cooling incubator
Device name
Serial No.
000000000000
Serial no. of the chamber
Built
2019
Year of construction
Nominal temperature
100 °C
212°F
Nominal temperature
IP protection
20
IP type of protection acc. to standard EN 60529
Temp. safety device
DIN 12880
Temperature safety device acc. to standard DIN 12880:2007
Class
3.1
Class of temperature safety device
Art. No.
9020-0112
Art. no. of the chamber
Project No.
---
Optional: Special application acc. to project no.
0,34 kW
Nominal power
1,5 A
Nominal current
230 V / 50 Hz
Nominal voltage +/-10% at the indicated power frequency
1 N ~
Current type
Max. operating pressure 15 bar
Max. operating pressure in the refrigerating system
R 134A - 0,075 kg
Refrigerant type and max. filling weight
Contains fluorinated greenhouse gases
covered by the Kyoto Protocol
Contains fluorinated greenhouse gases covered by the Kyoto
Protocol
Symbol on the type plate
Information
CE conformity marking
Electrical and electronic equipment manufactured / placed on
the market in the EC after 13 August 2005 and to be disposed
of in separate collection according to directive 2012/19/EU on
waste electrical and electronic equipment (WEEE).
Nominal temp.
100 °C
0,34 kW / 1,5 A
Max. operating pressure 15 bar
212 °F
230 V / 50 Hz
R 134A – 0,075 kg
IP protection
20
Contains fluorinated greenhouse gases
Safety device
DIN 12880
1 N ~
covered by the Kyoto Protocol
Class
3.1
Art. No.
9020-0112
Project No.
Built
2019
Cooling incubator
BINDER GmbH
Im Mittleren Ösch 5
78532 Tuttlingen / Germany
www.binder-world.com
KB 23
E3.1
Serial No. 00000000000000
Made in Germany
