KB 23 / KB 23-UL (E3.1) 02/2019 page 14/87
2.3 Chamber rear
(13)
(14)
Figure 5: Chamber rear with position of RS 422 interface
(13) Interface RS 422 for computer communication
(14) Power cable
3. Completeness of delivery, transportation, storage, and
installation
3.1 Unpacking, and checking equipment and completeness of delivery
After unpacking, please check the chamber and its optional accessories, if any, based on the delivery
receipt for completeness and for transportation damage. Inform the carrier immediately if transportation
damage has occurred.
The final tests of the manufacturer may have caused traces of the shelves on the inner surfaces. This has
no impact on the function and performance of the chamber.
Please remove any transportation protection devices and adhesives in/on the chamber and on the doors
and remove the operating manuals and accessory equipment.
CAUTION
Sliding or tilting of the chamber.
Damage to the chamber.
Risk of injury by lifting heavy loads.
∅ Do NOT lift or transport the chamber using the door, the handle, or the lower housing.
Lift the chambers from the pallet with the aid of two people in the area of all 4 chamber
feet.
