Display 1 shows
0000
Display 2 shows Shiftpt. 1
(selection of the shift point)
(actual shift point: 1)
Select the shift point (1 up to 4) with key
Value is shown in display 2.
Press program key
Display 1 shows
e.g. --.--
(time of the selected shift point)
Display 2 shows S1: --:--
(actual selection of the shift point: S1)
(actual setting: shift point not programmed)
Press program key
Display 1 shows
--.--
(time of the selected shift point)
Display 2 shows Time --:--
(entry of the time of the selected shift point)
(actual setting: shift point not programmed)
Enter the time (hh:mm) using arrow keys
Value is shown in display 2.
Press key
Display 1 shows
0000
Display 2 shows Ch1 = SP2: Off
(entry of the state of channel 1)
(actual setting: Off)
Enter the state of channel 1
(On or Off) using arrow keys
Setting is shown in display 2.
Press key
Display 1 shows
0000
Display 2 shows Channel 2: Off
(entry of the state of channel 2) (no function)
(actual setting: Off)
Enter the state of channel 2
(On or Off) using arrow keys
Setting is shown in display 2.
Press key
Press key EXIT
Display 1 shows
e.g., 08.30
(time of the selected shift point)
Display 2 shows S1: 08:30 - -
(actual selection of the shift point: S1)
(actual setting: time 08.30, channels Off)
Press key EXIT
Press key EXIT twice
Press program key
Select the next shift point Select the next day of the week
To exit the menu, press the EXIT key several times or wait for 120 seconds. The controller returns to
normal display.
