Troubleshooting
Controller
MB1 I/O-
board
(-3N2)
defective?
Binary outputs:
BA 1→ Cooling release
BA 2→ Solenoid valve (-7Y1)
large plate evaporator
BA 3→ Solenoid valve (-7Y2),
small plate evaporator
Yes
Replace controller MB1 I/O-board
(chap. 8.8.1)
Check acc. to chap. 4.4
No
Capillary tubes blocked?
Yes
Have replaced the capillary tubes
(chap. 10.4)
No
Loss of refrigerant?
Yes
Have the leak closed
