Chapter 7 LAN
In this menu, you configure the addresses in your LAN and can structure your local network
using VLANs.
7.1 IP Configuration
In this menu, you can edit the IP configuration of the LAN and Ethernet interfaces of your
device.
7.1.1 Interfaces
The existing IP interfaces are listed in the LAN->IP Configuration->Interfaces menu. You
can edit the IP configuration of the interfaces or create virtual interfaces for special applica-
tions. Here is a list of all of the interfaces (logical Ethernet interfaces and others created in
the subsystems) configured in the System Management->Interface Mode / Bridge
Groups->Interfaces menu.
Use the to edit the settings of an existing interface (bridge groups, Ethernet interfaces in
routing mode).
You can use the New button to create virtual interfaces. However, this is only needed in
special applications (e.g. BRRP).
Depending on the option selected, different fields and options are available. All the config-
uration options are listed below.
Change the status of the interface by clicking the or the button in the Action column.
Press the button to display the details of an existing interface.
Note
For IPv4 note that:
If your device has obtained an IP address dynamically from a DHCP server operated
in your network for the basic configuration, the default IP address is deleted automatic-
ally and your device will no longer function over this address.
However, if you have set up a connection to the device over the default IP address or
have assigned an IP address with the Dime Manager in the basic configuration, you
7 LAN bintec elmeg GmbH
134 bintec RS Series
