Field Description
MAC Address Displays the MAC address being used for this VSS.
Active Clients Displays the number of active clients.
2,4/5 GHz changeover Displays the number of clients who have been moved to a dif-
ferent frequency band by the 2,4/5 GHz changeover function.
Denied Clients soft/
hard
Displays the number of rejected clients after the absolute num-
ber of permitted clients has been reached.
20.5.4 Bridge Links
In the Monitoring->WLAN->Bridge Links menu, current values and activities of the bridge
links are displayed.
Fig. 235: Monitoring->WLAN->Bridge Links
Values in the Bridge Links list
Field Description
Bridge Link Descrip-
tion
Shows the name of the bridge link.
Remote MAC Shows the MAC address of the bridge link partner.
First seen Displays the time of the first registered attempted contact of the
bridge link partner.
Last seen Displays the time of the last registered attempted contact of the
bridge link partner.
Tx Packets Shows the total number of packets sent.
Rx Packets Shows the total number of packets received.
Signal dBm (RSSI1,
RSSI2, RSSI3)
Shows the received signal strength in dBm.
Noise dBm Shows the received noise strength in dBm.
Tx Data Rate mbps Shows the current clock rate of data sent on this bridge link in
20 Monitoring bintec elmeg GmbH
580 bintec RS Series
